SHIMPO PT-122 Contact Tachometer, Metric Units

Model: PT-122

SHIMPO PT-122 Contact Tachometer, Metric Units-


Downloads: datasheet manual

SHIMPO PT-122 Contact Tachometer, Metric Units

Model: PT-122

Features 3 unit selection and LCD display. Lightweight, ergonomic design allows comfortable long term usage.

Features 3 unit selection and LCD display. Lightweight, ergonomic design allows comfortable long term usage.

Sale Price $85.50 USD
Regular Price $95.00 USD
Availability 2 to 3 Weeks
Quantity

Add In-House Traceable Calibration to your PT-122

Add In-House Traceable Calibration to your PT-122


SHIMPO PT-122 Offers

The SHIMPO Model PT-121 Contact Tachometer is a simple to use, ergonomic, rugged test instrument for rotational speed applications.

This velocity analyzing and measuring device is ideal for rotational machine inspection and process speed analysis. The PT-121 possesses a large backlit LCD screen that provides clear viewing in any environment. With a simple selection switch users can obtain readings in either RPM, meters, meters per minute in metric models or RPM, feet and feet per minute in imperial models. During testing, the unit automatically saves maximum, minimum, last recorded values and up to 96 logged data readings.

Features


  • Large, backlit LCD for easy viewing in both bright and dim environments
  • Automatically records Maximum, Minimum, Last Value as well as up to 96 data points during testing
  • Quickly review after testing by pushing the MEM button
  • Includes contact wheel and cone adapters

Applications

Ideal for the following applications: Automobile, Aircraft Maintenance, Engineering Applications.

SHIMPO PT-122 Specifications

Range 0.5-19,999 RPM, 0.16-6559.6 ft/min, 0.16-99,999 ft
Display 5 digit, 0.7" (18 mm) LCD
Sampling Time 0.8 second (over 60 RPM)
Memory Automatically stores Maximum (UP), Minimum (dn), last value (LA) and up to 96 readings for review. Maximum speed for reading storage is every 0.8 seconds
Enclosure ABS plastic housing
Click here for complete specifications on the SHIMPO PT-122

What's included with the SHIMPO PT-122


  • PT-122 Tachometer
  •
  • 3 AAA batteries
  • Protective carrying case. Large & small cone adapter
  • Funnel
  • Surface wheel
  • 3.87" (98.3 mm) cir

Customer Reviews for the SHIMPO PT-122

Ask a question about SHIMPO PT-122 Contact Tachometer, Metric Units

SHIMPO PT-122 Offers

The SHIMPO Model PT-121 Contact Tachometer is a simple to use, ergonomic, rugged test instrument for rotational speed applications.

This velocity analyzing and measuring device is ideal for rotational machine inspection and process speed analysis. The PT-121 possesses a large backlit LCD screen that provides clear viewing in any environment. With a simple selection switch users can obtain readings in either RPM, meters, meters per minute in metric models or RPM, feet and feet per minute in imperial models. During testing, the unit automatically saves maximum, minimum, last recorded values and up to 96 logged data readings.

Features


  • Large, backlit LCD for easy viewing in both bright and dim environments
  • Automatically records Maximum, Minimum, Last Value as well as up to 96 data points during testing
  • Quickly review after testing by pushing the MEM button
  • Includes contact wheel and cone adapters

Applications

Ideal for the following applications: Automobile, Aircraft Maintenance, Engineering Applications.

SHIMPO PT-122 Specifications

Range 0.5-19,999 RPM, 0.16-6559.6 ft/min, 0.16-99,999 ft
Display 5 digit, 0.7" (18 mm) LCD
Sampling Time 0.8 second (over 60 RPM)
Memory Automatically stores Maximum (UP), Minimum (dn), last value (LA) and up to 96 readings for review. Maximum speed for reading storage is every 0.8 seconds
Enclosure ABS plastic housing
Click here for complete specifications on the SHIMPO PT-122

What's included with the SHIMPO PT-122


  • PT-122 Tachometer
  •
  • 3 AAA batteries
  • Protective carrying case. Large & small cone adapter
  • Funnel
  • Surface wheel
  • 3.87" (98.3 mm) cir

Ask a question about SHIMPO PT-122 Contact Tachometer, Metric Units

Customer Reviews for the SHIMPO PT-122
