SHIMPO FGE-100XY Digital Force Gauge 100lb/50.00kg/500.0N

Model: FGE-100XY

SHIMPO FGE-100XY Digital Force Gauge 100lb/50.00kg/500.0N-


Downloads: datasheet manual

SHIMPO FGE-100XY Digital Force Gauge 100lb/50.00kg/500.0N

Model: FGE-100XY

Combines a rugged, ergonomic and compact design with exceptional accuracy to provide a solid force testing instrument. The 1000Hz sample rate provides faster sampling producing better resolution and more accurate results.

Combines a rugged, ergonomic and compact design with exceptional accuracy to provide a solid force testing instrument. The 1000Hz sample rate provides faster sampling producing better resolution and more accurate results.

Sale Price $558.00 USD
Regular Price $620.00 USD
Availability 3 to 4 Weeks
Quantity

Add In-House Traceable Calibration to your FGE-100XY

Add In-House Traceable Calibration to your FGE-100XY


SHIMPO FGE-100XY Offers

Features

  • Ideal for strict tolerances with its high accuracy ±0.2% F.S.
  • Measure and record compression and tension tests, permits true "push-pull" testing
  • Simple one button adjustment changes units of measure, while pressing the peak button quickly produces the highest recorded value during the test
  • 180° reversible display and dual printed keypad allows usage as a portable gauge or mounted upside down on a test stand
  • Variable display response rate aids viewing readings
  • 1 million operation load cell with superior overload protection provides a long-life, damage free product
  • Rugged, ergonomic die cast aluminum construction allows usage on production floor
  • Dual power capable with rechargeable battery or AC line voltage

Performing a Puncture Test

A large variety of materials need to be able to withstand a specific threshold of puncture force in order to pass certain quality standards. Specifically Gypsum board, or drywall, must be tested in order to determine the ASTM Standard classification level of the product. ASTM C1629 provides details for classifying Abuse Resistance Non-decorated Interior Gypsum Panel Products and Fiber-Reinforced Cement Panels.

Quality Technicians needing to classify their products to this ASTM standard can utilize the Nidec-SHIMPO FG-M6PUNCTURE-ST adapter. Attaching this adapter to one of Shimpo's digital or mechanical force gauges creates an ideal testing kit for determining the indentation resistance.

The FG-M6PUNCTURE-ST adapter operation is quite simple. The outer shell of the FG-M6PUNCTURE-ST retracts as a load is applied to the test material. As the retraction of the outer shell occurs, the pin becomes exposed. The puncture test continues until the outer shell comes to a stop from contact with the base of the force gauge. The maximum force reading displayed on the gauge is the resultant puncture resistance of the test material.

The FG-M6PUNCTURE-ST combined with the Shimpo force gauge can be used to test puncture resistance on a multitude of materials such as: foam, cardboard, cork, tubing, membranes, baked goods, and even the ripeness of fruits or vegetables.

SHIMPO FGE Series Specifications

Accuracy 200% of F.S.
Data Sampling Rate 1000 Hz
Display 4-digit LCD, 0.5" (12 mm) high. Reversible by push-button. Minus sign for tension
Display Update Rate 0.05, 0.1, 0.2, 0.3, 0.5, 1 sec
Power Supply Rechargeable Ni-Cad battery or AC adapter/charger
Dimensions/Weight 5.8 x 3 x 1.5" (147 x 75 x 38 mm)/1 lb (450g)
Click here for complete specifications on the SHIMPO FGE-100XY

What's included with the SHIMPO FGE Series

  • Digital Force Gauge
  • 8 attachments (hook, chisel, flat tip, notched tip, hanger, cone tip, thread adapter, extension rod)
  • LinkRunner AT holster
  • AC adapter/charger
  • Carrying Case

Click on a category to view a selection of compatible accessories with the SHIMPO FGE-100XY Digital Force Gauge 100lb/50.00kg/500.0N.

SHIMPO FG-09V120UC Universal Adapter/Charger FG-09V120UC
120/240V AC Universal Adapter/Charger for TPN, TRC, FGE-XY, FGV-XY, FGE-HXY and FGV-HXY Series.




SHIMPO FG-M4PIN2 Aluminum Pin Head Grip, M4 Thread, 2mm FG-M4PIN2
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M4PIN1 Aluminum Pin Head Grip, M4 Thread, 1mm FG-M4PIN1
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M4PIN05 Aluminum Pin Head Grip, M4 Thread, 0.5mm FG-M4PIN05
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M4FLM20 Aluminum Wide Film Grip, M4 Thread FG-M4FLM20
20mm Grip for use with FGE and FGV Series Force Gauges.




SHIMPO FG-M4FPG3 Aluminum Fine Point Grip, M4 Thread, 3mm FG-M4FPG3
3mm Grip for use with FGE and FGV Series Force Gauges.




SHIMPO FG-M4FPG8 Aluminum Fine Point Grip, M4 Thread, 8mm FG-M4FPG8
8mm Grip for use with FGE and FGV Series Force Gauges.




SHIMPO FG-M4RD Aluminum Extension Rod, M4 Thread FG-M4RD
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M6RD Steel Extension Rod, M6 Thread FG-M6RD
The SHIMPO extension rod is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that extends the reach of the sensor and its attachments. It fits onto the sensor of the force gauge.




SHIMPO FG-M6RD-5IN Steel Extension Rod, 5in, M6 Thread FG-M6RD-5IN
The SHIMPO extension rod is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that extends the reach of the sensor and its attachments. It fits onto the sensor of the force gauge.




SHIMPO FG-M6ADP Standard Steel Adapter Set, M6 FG-M6ADP
Set Features a Chisel, Cone, Flat Head, Notched, Hook and Extension Rod. For use with FGE and FGV Series Force Gauges.




SHIMPO FG-M6CL Steel Chisel Adapter, M6 Thread FG-M6CL
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M6 thread and a 110 lb. (50 kg) capacity. It is made of stainless steel for good resistance to wear and corrosion.




SHIMPO FG-M6CN Steel Cone Head Adapter, M6 Thread FG-M6CN
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M6 thread and a 110 lb. (50 kg) capacity. It is made of stainless steel for good resistance to wear and corrosion.




SHIMPO FG-M6FL Steel Flat Head Adapter, M6 Thread FG-M6FL
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M6 thread and a 110 lb. (50 kg) capacity. It is made of stainless steel for good resistance to wear and corrosion.




SHIMPO FG-M6GV Steel Notched Head Adapter, M6 Thread FG-M6GV
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M6 thread and a 110 lb. (50 kg) capacity. It is made of stainless steel for good resistance to wear and corrosion.




SHIMPO FG-M6TJ10 Thread Adapter, M6 to 10/32 UNF FG-M6TJ10
The SHIMPO thread adapter is an accessory for SHIMPO force gauge test stands and force gauges. It fits onto a part or accessory to adapt one thread size to another and to convert it from male to female or female to male, allowing a variety of accessories and parts to be attached and swapped.




SHIMPO FG-M4ADP Standard Aluminum Adapter Set, M4 Thread FG-M4ADP
The SHIMPO adapter set for force gauges is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that comes with one hook, one extension rod, and four heads (one flat, one chisel, one pointed, and one notched) for testing on a variety of samples. The attachments fits onto the sensor of the force gauge.




SHIMPO FG-M4CL Aluminum Chisel Adapter, M4 Thread FG-M4CL
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M4 thread, and it is made of stainless steel, which resists corrosion and wear.




SHIMPO FG-M4CN Aluminum Cone Head Adapter, M4 Thread FG-M4CN
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M4 thread, and it is made of stainless steel, which resists corrosion and wear.




SHIMPO FG-M4FL Aluminum Flat Head Adapter, M4 Thread FG-M4FL
The SHIMPO steel head adapter is an accessory for SHIMPO FGE-X, FGV-X, and FGV-XY force gauges that fits onto the sensor of the gauge. The attachment has an M4 thread, and it is made of stainless steel, which resists corrosion and wear.




SHIMPO FG-M6TM10 Thread Adapter, M6 (FEM) to M10 (MALE) FG-M6TM10
The SHIMPO thread adapter is an accessory for SHIMPO force gauge test stands and force gauges. It fits onto a part or accessory to adapt one thread size to another and to convert it from male to female or female to male, allowing a variety of accessories and parts to be attached and swapped.




SHIMPO FG-M6HK Steel Hook Adapter, M6 Thread FG-M6HK
The SHIMPO force gauge hook is an accessory for SHIMPO force gauges that is used in tensile testing. It attaches to a force gauge to allow a load to be hooked onto the gauge.




SHIMPO FG-M6HKL Steel Large Hook Adapter, M6 Thread FG-M6HKL
The SHIMPO force gauge hook is an accessory for SHIMPO force gauges that is used in tensile testing. It attaches to a force gauge to allow a load to be hooked onto the gauge.




SHIMPO FG-M4HK Aluminum Hook Adapter, M4 Thread FG-M4HK
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M10HK Steel Hook Adapter, M10 Thread FG-M10HK
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M6PUNCTURE-ST Puncture Test Attachment, M6 Thread FG-M6PUNCTURE-ST
The SHIMPO FG-M6Puncture-ST is an accessory for the SHIMPO FGE and FGV Dart series force gauges that measures the puncture resistance of products such as gypsum wall board, foam, cardboard, fruit and vegetables, cork, plastic tubing, and membranes. It is threaded to fit onto the sensor of a compatible force gauge, and it measures 1.375" (34.91 mm) long.




SHIMPO FG-HANDLE Handle for FGE-XY and FGV-XY Digital Force Gauges FG-HANDLE
Handle adapter for larger loads.




SHIMPO FG-M10FL Steel Flat Head Adapter, M10 Thread FG-M10FL
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M10GV Steel Notched Head Adapter, M10 Thread FG-M10GV
For use with SHIMPO FGE and FGV Series Force Gauges.




SHIMPO FG-M4GV Aluminum Notched Head Adapter, M4 Thread FG-M4GV
For use with SHIMPO FGE and FGV Series Force Gauges.




Customer Reviews for the SHIMPO FGE-100XY

Ask a question about SHIMPO FGE-100XY Digital Force Gauge 100lb/50.00kg/500.0N

SHIMPO FGE-100XY Offers

Features

  • Ideal for strict tolerances with its high accuracy ±0.2% F.S.
  • Measure and record compression and tension tests, permits true "push-pull" testing
  • Simple one button adjustment changes units of measure, while pressing the peak button quickly produces the highest recorded value during the test
  • 180° reversible display and dual printed keypad allows usage as a portable gauge or mounted upside down on a test stand
  • Variable display response rate aids viewing readings
  • 1 million operation load cell with superior overload protection provides a long-life, damage free product
  • Rugged, ergonomic die cast aluminum construction allows usage on production floor
  • Dual power capable with rechargeable battery or AC line voltage

Performing a Puncture Test

A large variety of materials need to be able to withstand a specific threshold of puncture force in order to pass certain quality standards. Specifically Gypsum board, or drywall, must be tested in order to determine the ASTM Standard classification level of the product. ASTM C1629 provides details for classifying Abuse Resistance Non-decorated Interior Gypsum Panel Products and Fiber-Reinforced Cement Panels.

Quality Technicians needing to classify their products to this ASTM standard can utilize the Nidec-SHIMPO FG-M6PUNCTURE-ST adapter. Attaching this adapter to one of Shimpo's digital or mechanical force gauges creates an ideal testing kit for determining the indentation resistance.

The FG-M6PUNCTURE-ST adapter operation is quite simple. The outer shell of the FG-M6PUNCTURE-ST retracts as a load is applied to the test material. As the retraction of the outer shell occurs, the pin becomes exposed. The puncture test continues until the outer shell comes to a stop from contact with the base of the force gauge. The maximum force reading displayed on the gauge is the resultant puncture resistance of the test material.

The FG-M6PUNCTURE-ST combined with the Shimpo force gauge can be used to test puncture resistance on a multitude of materials such as: foam, cardboard, cork, tubing, membranes, baked goods, and even the ripeness of fruits or vegetables.

SHIMPO FGE Series Specifications

Accuracy 200% of F.S.
Data Sampling Rate 1000 Hz
Display 4-digit LCD, 0.5" (12 mm) high. Reversible by push-button. Minus sign for tension
Display Update Rate 0.05, 0.1, 0.2, 0.3, 0.5, 1 sec
Power Supply Rechargeable Ni-Cad battery or AC adapter/charger
Dimensions/Weight 5.8 x 3 x 1.5" (147 x 75 x 38 mm)/1 lb (450g)
Click here for complete specifications on the SHIMPO FGE-100XY

What's included with the SHIMPO FGE Series

  • Digital Force Gauge
  • 8 attachments (hook, chisel, flat tip, notched tip, hanger, cone tip, thread adapter, extension rod)
  • LinkRunner AT holster
  • AC adapter/charger
  • Carrying Case

Click on a category to view a selection of compatible accessories with the SHIMPO FGE-100XY Digital Force Gauge 100lb/50.00kg/500.0N.

SHIMPO FG-09V120UC Universal Adapter/Charger FG-09V120UC
120/240V AC Universal Adapter/Charger for TPN, TRC, FGE-XY, FGV-XY, FGE-HXY and FGV-HXY Series.
